Image Sensor |
2 MP CMOS |
|
Signal System |
PAL/NTSC |
|
Max. Resolution |
1920 (H) × 1080 (V) |
|
Min. Illumination |
0.02 Lux @ (F1.2, AGC ON), 0 Lux with IR |
|
Shutter Time |
PAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s |
|
Angle Adjustment |
Pan: 0° to 360°, Tilt: 0° to 75°, Rotation: 0° to 360° |
|
Lens Type |
2.8 mm, 3.6 mm Fixed Lens |
|
Focal Length & FOV |
2.8 mm, horizontal FOV: 96.5°, vertical FOV: 48.9°, diagonal FOV: 120.5° 3.6 mm, horizontal FOV: 76.9°, vertical FOV: 40.6°, diagonal FOV: 92.0° |
|
Lens Mount |
M12 |
|
Illuminator |
Supplement Light Range Up to 20 m |
|
Frame Rate |
TVI: 1080p@25fps/30fps AHD: 1080p@25fps/30fps CVI: 1080p@25fps/30fps CVBS: PAL/NTSC |
|
Dimension |
Φ 84.6 mm × 78.9 mm (Φ 3.33" × 3.11") |
|
Weight |
Approx. 195g (0.43 lb.) |
|
Power |
12 VDC ± 25%, Max. 3.3 W |
