Scanner Type

A4 sheet-fed, one-pass duplex colour scanner

Sensor Type

Colour Contact Image Sensor (CIS) x 2

Scanning Method

Fixed carriage and moving document

Light Source

RGB LED x 2

Output Resolution

50 – 1,200 dpi (in 1 dpi increments)

Bit Depth

Color: 30-bit input, 24-bit output

Grayscale

10-bit input, 8-bit output

Black and White

10-bit input, 1-bit output

Document Size

Minimum 50.8 x 50.8 mm

Maximum 215.9 x 3,048 mm

Supported Paper Weight

Vertical Path: 40 – 127 g/m2 , Less than A6 size: 40 – 209 g/m2

Straight Path: 40 – 413 g/m2

ADF Capacity

20 sheets (80 g/m2 )

Daily Scan Volume

Up to 5,000 sheets / day

Multi-feed Detection

Length Detection

Interface

USB 2.0

Optical Resolution

600 x 600 dpi

Rated Voltage

AC 220 - 240 V

Rated Frequency

50 - 60 Hz

Power Consumption

Operating: Approx. 10 W

Ready Mode: Approx. 3.3 W

Sleep Mode: Approx. 1.0 W

Power Off: Approx. 0.1 W

Temperature

Operating: 5 - 35 °C

Storage -25 - 60 °C

Humidity

Operating 15 - 80 % (No Condensation)

Storage 15 - 85 % (No Condensation)

Supported OS (Scanner Driver)

Windows: Windows 7 / 8 / 8.1 / 10 / 11, Server 2008 / 2012 / 2016 / 2019 / 2022

Mac: Mac OS X 10.9 or later

Driver compatibility

TWAIN, SANE, WIA, ICA, ISIS

Dimensions (W x D x H)

296 x 104 x 125 mm

Weight

1.8kg
